The Russound MCA-66 Digital multi-zone controller amplifier provides up to six zones of distributed audio. Scalable to 36 zones, the MCA-66 provides numerous options to tailor every room in residential or light commercial distributed audio systems. A variety of input options have been engineered into the MCA-66 to connect up to 6 sources. AV source input options include 6 Analog, 3 Digital (up to 3 coax, or 2 coax and 1 optical), 1 paging and 1 Bluetooth extender connection. The Bluetooth connection allows the installation of the MCA-66 in an equipment rack while remotely locating the optional Russound BTC-2X Bluetooth receiver up to 500’ away in or near the room where the Bluetooth source will be located. An RNET link allows for metadata transmission, linking multiple MCA controllers and connection to all Russound RNET Smart Sources like the ST1 AM/FM external tuner.

Product highlights:

• multi-zone controller and power amp for Russound multi-room audio systems
• distributes music from six sources to up to six listening areas in your home
• expandable up to 36 zones with additional controller/amplifiers
• 6 RCA stereo inputs
• 2 coaxial digital and 1 optical/coaxial digital inputs
• 6 pairs of speaker connectors
• 20 watts RMS x 12 at 8 ohms
• zones 1 and 2 line-level outputs (fixed or variable)
• supports RS-232 and IP-control for integrating a third-party home automation system
• supports voice control via an Amazon Alexa device
• 6 RJ-45 ports for connecting optional in-wall keypads via category cable
• 6 routed IR outputs and 1 common IR output
• 12-volt trigger input and output
• supports Bluetooth® streaming with optional BTC-2X or BTC-1X receiver
• rack-mountable with (mounting ears included)
• 17"W x 3-3/4"H x 13-1/2"D
• weight: 19.2 lbs.
