Rotel Michi S430 Stereo Power Amplifier

The Rotel Michi Prestige S430 Stereo Power Amplifier brings commanding power, refined control, and elegant high-end engineering to premium two-channel audio systems. Rated at 230 watts per channel into 8 ohms, with 390 watts per channel maximum output into 4 ohms, the S430 is designed to drive high-performance loudspeakers with authority, dynamic headroom, and musical precision. Its Class AB amplifier design is supported by an oversized in-house manufactured toroidal transformer, high-efficiency bulk storage capacitors, symmetrical circuit traces, and carefully selected signal-path components for faithful music reproduction. Balanced XLR and unbalanced RCA inputs, dual 5-way speaker binding posts, 12V trigger control, a front-panel TFT display, and an included remote control make the S430 a powerful and polished centerpiece for a serious stereo system.

Specifications:

• Amplifier Class: Class AB
• Power Output (FTC): 250 watts/channel into 8 ohms
• Continuous Power Output (Non FTC): 230 watts/channel into 8 ohms
• Maximum Power Output (Non FTC): 390 watts/channel into 4 ohms
• Total Harmonic Distortion: < 0.03%
• Intermodulation Distortion: < 0.03% at 60 Hz : 7 kHz, 4:1
• Frequency Response: 10 Hz–100 kHz, 0 ± 0.4 dB
• Damping Factor: 350 at 1 kHz, 8 ohms
• Speaker Impedance: 4 ohms minimum
• Signal-to-Noise Ratio: > 115 dB, IHF “A” weighted
• Crosstalk/Separation: > 70 dB
• Input Sensitivity/Impedance, Unbalanced: 2 V / 12k ohms
• Input Sensitivity/Impedance, Balanced: 4 V / 200k ohms
• Gain, Unbalanced: 26.5 dB
• Gain, Balanced: 20.5 dB
• Power Requirements, Europe: 230 V, 50 Hz
• Power Requirements, USA: 120 V, 60 Hz
• Power Consumption: 550 watts
• Standby Power Consumption: < 0.5 watts
• Power Supply: High-current linear power supply
• Transformer: Oversized custom-engineered, in-house manufactured toroidal transformer
• Capacitors: High-efficiency bulk storage capacitors; custom-made slit foil capacitors
• Circuit Design: Symmetrical circuit traces
• Signal Path Components: Metal film resistors and polystyrene or polypropylene capacitors in key signal paths
• Analog Inputs: RCA unbalanced inputs and balanced XLR inputs
• Speaker Outputs: Dual precision 5-way speaker binding posts
• Speaker Connection Support: Single-wire and bi-wire speaker configurations
• Speaker Connector Compatibility: Bare wire, connector lugs, or dual banana plugs where permitted
• 12V Trigger: 12V trigger input and output
• Trigger Input Range: Accepts 3 V to 30 V AC or DC control signal
• USB Port: Rear USB port for software updates
• Service Port: Rear service port for factory service use only
• AC Power Input: Rear AC power input
• Display: Front-panel TFT display
• Display Views: Selectable VU meter and spectrum display views
• Front Panel Controls: Power button and indicator, display, remote sensor
• Remote Control: Includes RR-MH31 remote control
• Remote Functions Used: Power, navigation, OK, dim, setup
• Remote Functions Not Used on S430: Mute, volume, audio, source, and preset buttons
• Remote Batteries: Requires two AAA batteries
• Balanced XLR Pin Assignment: Pin 1 ground/screen, Pin 2 hot/in phase, Pin 3 cold/out of phase
• Protection Circuitry: Thermal and over-current protection
• Recommended Ventilation Clearance: Minimum 10 cm / 4 in of unobstructed clearance around the chassis
• Installation Note: Plug directly into a polarized wall outlet using the supplied cable or a high-current compatible cable; do not use an extension cord
• Compliance Notes: Designed to comply with RoHS and WEEE directives
• Dimension: 17"W x 5 5/6"H x 16"D
• Net Weight: 38.6 lbs
• Finish: Black
