Revel W226Be In-wall speaker with dual 6-1/2" woofers

 beryllium-tweeter, dual-woofer in-wall speaker from Revel

If you're looking for high-performance, zero-footprint home theater sound, these in-wall speakers from Revel are tough to beat. It starts with super-clear high-frequency detail from its 1” beryllium tweeter. Beryllium is known for being both ultra-light and very rigid — properties that allow the tweeter to deliver exquisitely smooth detail without distortion. Dual neodymium magnets control the tweeter's movement with precision, and an acoustic lens waveguide provides a cohesive sound stage throughout your room.

Dual 6-1/2” woofers flank the tweeter, for sound that's rich and full. They also let you install the speakers vertically or horizontally — that means you can use them as left, right, and center-channel speakers in a home theater system. Each woofer features Revel's Deep Ceramic Composite (DCC) construction, with an aluminum cone sandwiched between two layers of ceramic coating. This design provides excellent damping for tight bass response. You can also use the W226BeBB backbox (sold separately) to ensure optimum sound and help keep it from bleeding into adjacent rooms.

Part of your Revel PerformaBe home theater system

The W226Be shares the same acoustic signature sound as Revel's popular PerformaBe line. That means you can get great results when you pair this speaker with bookshelf, floor-standing, and center channel models in your custom home theater setup.

Product highlights:

• ideal for a high-performance in-wall home theater system
• can be mounted horizontally or vertically for use as a left, right, or center-channel speaker
• 1" beryllium dome tweeter
  • dual neodymium magnets for extremely accurate high-frequency reproduction
  • acoustic lens waveguide ensures seamless sound with woofers
• two 6-1/2" Deep Ceramic Composite (DCC) woofers
  • coarse ceramic coating on either side of aluminum core for excellent damping and reduced distortion
  • optimized motor magnetics for improved mid- and low-frequency performance
• high-order crossover network delivers accurate timbre reproduction
• frequency response: 45-40,000 Hz (-6 dB)
• recommended amplifier power: 50-200 watts at 4 ohms
  • high-performance amplifier recommended
• nominal impedance: 6 ohms; minimum impedance: 4 ohms
• maximum SPL: 110 dB
• sensitivity: 90 dB

Other info:

• zero-bezel magnetic grille is paintable to match your decor
• cat's claw mounting system for wallboard or optional W226BeBB backbox installations
• compatible wall-thickness range: 3/8"-1"
• speaker cutout: 21-5/8" x 8-15/16"
• mounting depth: 3-9/16"
• dimensions with grille: 10-1/4"W x 22-15/16"H x 3-13/16"D
• weight: 15.7 lbs. (with grille)
