The Pass Labs XA30.8 power amplifier is an exceptional stereo power amplifier on many levels — high-biased MOSFETs providing higher-power class A operation, direct-coupled front-end circuitry for exceptionally high stability and larger, more robust heats sinks similar to those of the larger .8 amplifiers. The list goes on, but listening may tell you the Pass Labs XA30.8 power amplifier represents a value high-point — quite possibly your particular optimal balance between performance and cost.
Specifications
| Class | A |
| Type | Stereo |
| Gain (dB) | 26 |
| Full Pwr @ 26 dB gain (V) | 0.77 |
| Low Frequency Response | 1.5 Hz |
| High Frequency Response | 100 KHz |
| Power Output /ch (8 ohm) | 30 |
| Input Impedance (SE & BAL Kohms) | 50/100 |
| Damping Factor | 150 |
| Power Consumption @ Idle (Watts) | 370 |
| Unit Dimension (W x D x H)(In.) | 19 x 21.25 x 7.5 |
| Unit Weight (LBS) | 88 |
