description

• Nº531H Highlights

  • Reliable, high-power in four different channel configurations provide ideal solutions for any system
  • Ethernet and 12V trigger control capability for system integration
  • Isolated chassis and signal grounds minimize noise, optimizing detail, even at low listening levels
  • Fully-differential circuitry with both balanced XLR and single-ended RCA inputs
  • Height (with feet): 7.65" (19.4cm); (without feet): 6.97" (17.7cm)
  • Width: 17.75" (45.1cm)
  • Depth: 19.83" (50.4cm)
  • Weight: Net Weight: 52.5lb (23.8kg); Shipping weight: 62.5lb (28.4kg)
  • Communication and Control: One Ethernet 10Base-T port; one 3.5mm mono (tip/sleeve) mini plug trigger input, 3-12Vdc; one 3.5mm mono (tip/sleeve) mini plug trigger output, 3-12Vdc; 3-pin IEC standard power connector
  • Inputs: One balanced XLR input per channel; one unbalanced RCA input per channel
  • Rated Output Power Into 8 Ohms: 300W/ch (20Hz to 20kHz)
  • Gain: 26.8dB
  • Power Requirements: 100V~, 120V~, 230V~, factory set for destination country
  • Speaker Connections: One pair “Hurricane” loudspeaker outputs with banana-plug sockets per channel (banana-plug socket not available on the 230 VAC models)

  ---

  General Specifications

  Frequency Response	Within 0.5dB from 10Hz to 20kHz
  Input Impedance	60 kΩ (balanced); 30 kΩ (unbalanced)
  Input Sensitivity	2.83Vrms output at 130mVrms input

  Audio Specifications

  Frequency Response	Within 0.5dB from 10Hz to 20kHz
  Input Impedance	60 kΩ (balanced); 30 kΩ (unbalanced)
  Input Sensitivity	2.83Vrms output at 130mVrms input

•
