Marantz Model 10: A Masterpiece of Audio Engineering

Experience the pinnacle of audio performance with the Marantz Model 10. This flagship integrated amplifier is meticulously crafted to deliver unparalleled sound quality, power, and elegance.

Key Features:

• Unmatched Power and Precision: Boasting dual-mono symmetrical amplifier topology and Purifi switching amplifiers, the Model 10 delivers a staggering 250W per channel (8 ohms) and 500W per channel (4 ohms). Experience dynamic, room-filling sound with exceptional clarity and detail. The amplifier's ability to effortlessly drive demanding speakers ensures a truly immersive listening experience.
• Iconic Design: The Model 10's sleek, brushed aluminum chassis and illuminated mesh grille are a testament to Marantz's commitment to both performance and aesthetics. The design is not only visually striking but also enhances the amplifier's internal components and cooling efficiency.
• Marantz Signature Sound: Immerse yourself in the rich, warm, and detailed sound that Marantz is renowned for. Every note is reproduced with stunning accuracy and emotion. The Model 10's ability to capture the nuances and subtleties of music recordings is unparalleled.
• Advanced Features: Enjoy a high-resolution OLED display, phono stage with selectable load impedance, and a fully balanced design for the ultimate listening experience. The OLED display provides clear and intuitive information, while the phono stage ensures compatibility with a wide range of vinyl cartridges. The fully balanced design minimizes noise and interference, resulting in a cleaner and more transparent sound.

Beyond its exceptional performance and elegant design, the Marantz Model 10 is a testament to Marantz's commitment to innovation and craftsmanship. The amplifier's internal components are meticulously engineered to ensure optimal sound quality and reliability. The use of premium materials and advanced manufacturing techniques guarantees a product that will stand the test of time.

If you're seeking an amplifier that will elevate your listening experience to new heights, the Marantz Model 10 is the perfect choice. Its combination of power, precision, and elegance makes it a true masterpiece of audio engineering.

Marantz Model 10 Specifications

General Specifications:

• Unit Dimensions (W × H × D): 440 × 192 × 473 mm
• Cabinet Size: 440 × 192 × 422 mm
• Net Weight: 33.7 kg
• Packaging Dimensions (W × H × D): 600 × 379 × 540 mm
• Packaging Gross Weight: 39.0 kg
• Carton Color: 1 Color (Material color: Brown, Printing: Black)
• Panel Color: Black / Marantz Champagne
• Front (Center) Panel: Anodized machined aluminum
• Back-shell: Anodized machined aluminum
• Front Panel Illumination: Yes (All sides, Dimmer)
• Side Cover: Aluminum (Thickness: Max 15.8 mm)
• Top Cover: Aluminum (Thickness: 6 mm)
• Top Cover (Center) Ventilation Hole Material: Stainless mesh
• Interior Illumination: Yes, dimmable
• Rear Panel: Copper Plated
• Chassis Material: Copper Plated
• Bottom Layer / Bottom Plate: Triple layer, Copper plated
• Volume Knob: Solid aluminum (Bearing construction)
• Input Selector: Solid aluminum (Bearing construction)
• Foot: Solid Aluminum, Copper plated (Height: 18.5 mm)
• Heatsink for Power Amplifier: Extruded Aluminum

Audio Specifications:

• Rated Output Power:
  • 250W + 250W (8 ohm, 20Hz-20kHz, THD 0.05%)
  • 500W + 500W (4 ohm, 20Hz-20kHz, THD 0.05%)
• Speaker Impedance: 4~16 ohm
• Frequency Response:
  • 5Hz~60kHz +0dB/-3dB
  • 20Hz~20kHz +0dB/-0.3dB
• Total Harmonic Distortion: 0.005% (125W, 8 ohm, 20-20kHz) (CCIF IMD, DFD IMD)
• Damping Factor: 500 (8 ohm, 20Hz-20kHz)
• Input Sensitivity:
  • Phono Input:
    • MM: 3.6 mV / 36 kohm
    • MC (Low): 400 µV / 33 ohm
    • MC (Mid): 400 µV / 100 ohm
    • MC (High): 400 µV / 390 ohm
  • CD/LINE/RECORDER: 350 mV/41 kohm (Unbalanced), 700 mV/36 kohm (Balanced) (Gain = 42dB)
  • Power Amp Input: Unbalanced: 1.58V / 41 kohm (Gain: 29dB), Balanced: 3.16V / 15 kohm (Gain: 24dB)
• RIAA Deviation: 20 Hz - 20 kHz ±0.5 dB (MM/MC)
• Phono Maximum Input:
  • MM: 80 mV
  • MC: 8 mV
• Signal-to-Noise Ratio:
  • PHONO (MM): 88 dB
  • PHONO (MC): 76 dB
  • CD: 122 dB
  • Balanced: 122 dB
• Headphone Output Level: 130 mW / 32 ohms
• Tone Control:
  • BASS: 50Hz ±10 dB
  • TREBLE: 15kHz ±10 dB
• Power Consumption: 270 W
• Standby Power Consumption: 0.1 W

Audio Features:

• Power Amplifier Circuit: Switch Mode BTL
• Power Transformer: Toroidal transformer in shielding case for preamplifier section only
• Power Supply: SMPS for Power amplifier, L/R independent
• Pre Amplifier Circuit: New HDAM High Grade, Full balance
• Volume Control: Electric / Variable gain
• Tone Control: Electric (Bass / Treble / Balance Control)
• Headphone Circuit: HDAM-SA2 + Diamond buffer
• Source Direct: Yes
• Power Amp Mode: Turns off Pre-Amp power supply
• Mono Mode: Yes
• Switch: Stereo / Bi-Amp on Rear Panel

Connectivity:

• Phono Input: Yes (MM / MC) with Marantz Musical Premium Phono EQ and Selectable MC impedance (3 positions)
• Analog Input (including Phono) / REC Out (RCA): 4 / 1 (Thick nickel-plated independent terminals)
• Balanced XLR Input: 2
• Power Amp Direct: Yes [RCA (Thick nickel-plated independent terminals) / XLR]
• Pre Out: Yes [RCA (Thick nickel-plated independent terminals) / XLR]
• Speaker Output: 2 sets (Bi-wiring)
• Speaker Terminal: Marantz Original SPKT-100+ (High quality and high-purity copper plated)
• Headphone Output: 1 (Automatically turns off the speaker when headphone is inserted)

Control and Other Features:

• Remote Control Bus Terminal: Yes (RC-5 In / Out)
• Remote Internal / External Switch: Yes
• Flasher Input: Yes
• AC Inlet: Yes
• Floating Control Bus System (F.C.B.S.): Yes
• Remote Controller: 10 series Universal Remote Control
• Unit Control (Button): Tact Switch (POWER)
• Unit Control (Knob): 2 (VOLUME, INPUT SELECTOR)
• LED Indicators:
  • POWER: 1 White
  • Protection: 1 Orange
  • Illumination (Edge): White
  • Interior: White
• Front Panel Display: New HD TFT Color Display
• Dimmer for Front Display: 20 steps
• Level Meter: Yes (HD Display)
• Volume Display: -Infinity/-99.5dB - 0dB / 0.5 step (default), 0-100 / 0.5 step (switchable)
• Last Function Memory: Yes
• Auto Standby Mode: Yes
• Remote Controller: RC004PMND
• Battery: Yes (AAA ×2)
• Power Cord: Yes (ALL region / Audio Grade / OFC)
