JBL Conceal C86 8-inch (200mm) Dual Panel, 5-element Invisible Loudspeaker (each)

PRICE:
Regular price $2,200.00 USD
Regular price $2,200.00 USD Sale price $2,200.00 USD
Sale Sold out

Shipping calculated at checkout.

CONDITION: New

description

JBL Conceal C86

The flagship of the Series, the JBL Conceal C86 Invisible Loudspeaker is a 3-way, dual panel design, with a separate LF panel and a 5-driver 2-way MF/HF panel. Built around a patented compression molded baffle and paintable Fidelity Glass™ outer skin, the finished loudspeaker panels install easily and disappear completely into the surrounding walls, allowing optimal placement virtually anywhere in a room. The JBL C86 is the ultimate solution for high-performance architectural audio.

Front. JBL - Conceal C86 8-inch (200mm) Dual Panel, 5-element Invisible Loudspeaker - Gray.

General Specifications

                                                                  Type
                           3-way In-Wall/In-Ceiling loudspeaker
                                                     Low Frequency Driver
              8-inch (203mm) woofer with 1.5-inch (38mm) voice coil
                                                    Mid Frequency Driver
  Four 1.18-inch (30mm) voice coil transducers with neodymium magnets
                                                  High Frequency Driver
        1-inch (25mm) voice coil transducer with neodymium magnet
                                           Recommended Amplifier Power
                                              50 - 200 WRMS
                                                           Impedance
                                                    4 Ohm
                                               Loudspeaker Sensitivity
                          84 dB/1W/1m measured in-room
                                                    Frequency Response
                 45 Hz - 20 kHz (-6 dB) measured in-room
                                                   Crossover Frequencies
                                          600 Hz; 10 kHz
                                                      Enclosure Type
                            Sealed, with wooden back-box
                                                           Protection
            Three independent self-resetting devices (LF, MF and HF)
                                                           Input Type
                   Dual gold-plated spring-loaded binding posts
                                                           Warranty
                                                  5 Years

Dimensions

                                          Mid-High Frequency Panel Dimensions
      11-7/8" H x 15 -7/8" W x 3-7/8" D (302mm H x 403mm W x 98mm D)
                                            MF/HF Panel Cut-out Dimensions
                              12” H x 16” W (305mm H x 406mm W)
                                              MF/HF Panel Mounting Depth
                                          3-3/8-inches (86mm)
                                            Low Frequency Panel Dimensions
      22" H x 15-7/8" W x 3-7/8" D (559mm H x 403mm W x 98mm D)
                                               LF Panel Cut-out Dimensions
                            22-1/8” H x 16” W (562mm H x 406mm W)
                                                 LF Panel Mounting Depth
                                         3-3/8-inches (86mm)
                                              Product Weight (MF/HF Panel)
                                                 12.9 lbs (5.9kg)
                                                 Product Weight (LF Panel)
                                              20.0 lbs (9.1kg)
                                                         Shipping Weight
                                               41.5 lbs (18.8kg)
