Bryston BD225

DYNAMIC HEADROOM
One of the concerns with Class D designs is the power supply section typically utilizing a ‘Switching’ supply. When your system runs out of what is
called ‘dynamic headroom’, it often clips, adding distortion to the signal
and deflating the sonic energy in the music. Bryston Class D amplifiers
use large ‘LINEAR’ toroid power supplies and large filter capacitors with
our proprietary (yes they are our own design) Bryston designed Class D amplifier modules to remove any hint of dynamic compression.

This combination of a huge toroidal transformer and lots of storage capacitance means you have usable power many times the continuous rated
power and that results in dynamic and distortion free listening.

FLEXIBILITY
The Bryston Class D amplifiers use a ‘common’ chassis with the option of
1, 2, 3, 4, 5, or 6 independent Class D modules. This provides excellent
versatility for multiple channel passive or active speakers or auxiliary
channels in a multi-channel surround system.

Features and Specifications

• Frequency Response (6 ohms-3dB) : 1Hz - 45kHz
• AC Input Voltage : 115 or 230
• RCA Input (Single Ended) : Yes
• Sensitivity : 1.5 volts
• Signal to Noise Ratio : 103dB (at full power)
• 12 Volt Trigger : Yes
• Voltage Gain2 : 9dB
• XLR Input (Balanced) : Yes
• Capacitance : 108,000uf
• Continuous RMS Wattage per channel into 8 ohms 225 watts
• Continuous RMS Wattage per channel into 4 ohms 450 watts
• Continuous RMS Wattage available to all channel 1250 watts
• Dynamic Wattage (100ms) available to all channels 3750 watts
• Weight (lbs) each : 53
• Weight (kg) each : 24
• Dimensions H W D (inches) : 5.25" x 17.75" x 16.75"
• Dimensions H W D (mm) : 133 x 450 x 425

Faceplates Options

• Personalized Faceplates
• Colour Faceplates Available

Dimensions

• Inches : 17.75 W x 5.25 H x 16.75 D | Cm: 45.1 W x 13.3 H x 42.5 D
• Weight : 53 lbs | 24 kg
• Frequency Response: 1Hz - 45kHz: 6 ohms-3dB
• Signal To Noise : 103dB (at full power)
• Sensitivity : 1.5 volts
• AC Input Voltage : 115 or 230
