Carbon Dome tweeters are a brand new technology purpose-built for the 700 Series. Delivering a dramatic improvement on the aluminium double dome tweeter, they raise the breakup threshold to 47kHz, for pinpoint imaging accuracy and detail.
Voices and instruments are delivered with purity and precision, thanks to the smooth, accurate Continuum™ cone midrange driver.
The midrange drivers in these floor-standers feature decoupled design, adapted from a similar system in the 800 Series Diamond. Decoupling reduces cabinet coloration, and boosts midrange clarity.
Dimensions | Height: 990mm (39 in) cabinet only 1025mm (40.4 in) including plinth Width: 200mm (7.9 in) cabinet only 320mm (12.6 in) including plinth Depth: 300mm (11.8 in) cabinet only 321mm (12.6 in) including grille and terminals 370mm (14.6 in) including plinth |
Net weight | 25.0kg (55.2 lb) |
Technical features | Decoupled Carbon Dome tweeter Continuum™ cone FST midrange Decoupled midrange Aerofoil™ Profile bass cones Flowport™ |
Description | 3-way vented-box system |
Drive units | 1x ø25mm (1 in) Decoupled Carbon Dome high-frequency 1x ø150mm (6 in) Continuum cone FST midrange 2x ø165mm (6.5 in) Aerofoil profile bass |
Frequency range | -6dB at 30Hz and 33kHz |
Frequency response | 46Hz - 28kHz ±3dB |
Sensitivity | 89dB spl (2.83Vrms, 1m) |
Harmonic distortion | 2nd and 3rd harmonics (90dB, 1m) <1% 90Hz - 22kHz <0.5% 120Hz - 20kHz |
Nominal impedance | 8Ω (minimum 3.1Ω) |
Recommended amplifier power | 30W - 200W into 8Ω on unclipped programme |
