ARCAM's flagship A/V receiver, the AVA35, has an advanced 9-channel amp and the same high-performance DAC architecture found in the British hi-fi company's top integrated amps. The sound is pristine and musical, perfect for high-res audio files or Dolby Atmos and DTS:X soundtracks. Plus, the 16-channel preamp outputs offer expansion capability so your system can grow with you.
For those who refuse to compromise, the AVA35 represents the summit of home cinema and musical performance. This is not just an amplifier—it’s ARCAM’s most advanced integrated AV solution, designed for true connoisseurs of sound.
Expertly engineered in Cambridge, UK, the AVA35 harnesses our signature Class G amplification, a technology unique to ARCAM and revered for its ability to deliver superior power, lower crossover distortion, and unmatched musicality. Combined with the same high-performance DAC architecture found in our flagship stereo systems, the AVA35 ensures every note and every cinematic moment is rendered with breathtaking clarity and emotional impact.
For the ultimate in flexibility, the AVA35 introduces matrix channel assignment, allowing you to reallocate channels freely for the most personalised and immersive configurations. Whether it’s music, movies, gaming, or sport, this amplifier adapts to your vision of perfection.
With nine channels of Class G power, 16-channels of Dolby Atmos, DTS:X, IMAX Enhanced and AURO-3D processing, and Dirac Live room correction, the AVA35 transforms your space into a world-class listening environment.
At ARCAM, sound quality isn’t just a promise—it’s our obsession. The AVA35 is the pinnacle of rigorous testing and listening sessions, more than deserving of the ARCAM name.
And with a vibrant 6.5" colour display, intuitive menus, and the Radia App, control is effortless—because the experience should be as seamless as the sound.
Nine channels of high power ARCAM Class G Amplification.
Dolby Atmos - Bring even the smallest details to life with sound that moves in all directions.
DTS:X and IMAX Enhanced, place sound where it would occur naturally in space, creating the most lifelike, multi-dimensional audio experience ever.
AURO-3D A revolutionary way of delivering audio that wraps you in a cocoon of life-like sound.
Matrix Channel Assignment for the flexibility to assign up to 16-channels for the best performance of your system
Dirac Live Room Correction for exceptional, calibrated audio in any room - upgrade with Dirac Live Bass Control and Dirac Live Active Room Treatment
Back-lit, Bluetooth remote control for continuous out-of-sight control
Works with the new ARCAM Radia AV Control app for setup, control, Internet Radio, Podcasts and UPnP playback from iOS, Android and Windows devices and PCs.
Works with Spotify Connect, Tidal Connect and Qobuz Connect, with direct connection from lossless music services
Roon Ready
Supports Apple Airplay and Google Cast
Bluetooth with Snapdragon Sound and Auracast for the best wireless sound with the most convenience
Large High-resolution display for clearly visible status and metadata from the comfort of your main listening position
Specifications
Maximum Channel Count: 16
Reassignable Channels:
All channels (Subwoofers into CH4 & 11-16 only)
Supported Decoding and Encoding:
Dolby Atmos, Dolby TrueHD, Dolby Atmos Height Virtualisation, Dolby Surround
DTS:X, DTS HD Master, DTS Neural:X, DTS Virtual:X
MPEG H
IMAX Enhanced
AURO-3D, AURO-2D
Inputs/Outputs: 7/3 (Zone 1 outputs = 2, Zone 2 outputs = 1)
HDMI/HDCP Versions: 2.1a/2.3
Resolution support (resolution/framerate):
Up to 8K/60Hz or 4K/120Hz
Supported Dynamic Range Profiles:
HDR, HDR10, HDR10+, HDR10+ Gaming, Dolby Vision, HLG
Supported HDMI features:
Variable Refresh Rate (VRR), Auto Low Latency Mode (ALLM), CEC, eARC/ARC (Zone 1, Output 1) On Screen Display
Works with (apps):
ARCAM Radia AV Control, Spotify Connect, Tidal Connect, Qobuz Connect, Roon (Ready)
Works with (services):
Apple Airplay, Google Cast, Internet Radio, Podcasts, UPnP
Supported Hi-res media:
FLAC, WAV (LPCM), AAC, ALAC, AIFF, MP3, OGG
Gapless Playback Supported
Supported Hi-res Bit depth: 16, 24
Supported samples rates (kHz): Up to 192 kHz
Frequency response: 20Hz—20kHz ± 0.05dB
Number of inputs (Coaxial/Toslink): 2/2
Supported Sample Rates (kHz):
Coaxial (RCA): 192, 176.4, 96, 88.2, 48, 44.1
Optical (Toslink): 96, 88.2, 48, 44.1
Bit depths (bit) (Coaxial/Toslink): 24, 16
Frequency response: 20Hz—20kHz ± 0.2dB
Signal/noise ratio (A-wtd, ref. 50W, 0dBFS): 100dB
Number of inputs: 3 (RCA pairs)
Signal/noise ratio (A-wtd, ref. 50W, 1V input): 100dB
Frequency response: 20Hz—20kHz ± 0.2dB
Number of Outputs RCA/XLR: 16/0
Single-ended (RCA) peak output level per channel: 2V RMS
THD+N (20 Hz to 20 kHz): –100dB
Amplifier Channels: 9, Class G
8O, 20Hz - 20kHz, 2 channels driven: 145W
4O, 1kHz, 2 channels driven: 200W
8O, 20Hz - 20kHz, 7 channels driven: 110W
4O, 1kHz, 7 channels driven: 130W
Harmonic distortion @80% power, 8O at 1kHz: 0.004%
Mains voltage (V/Hz): 100–120V or 220–240V, 50–60Hz
Max Power consumption: 900W
Max Thermal dissipation: 3070 BTU/hour
Idle Power consumption: 93W
Idle Thermal dissipation: 320 BTU/hour
Standby Power consumption (Default/Low Power): 2W/0.4W
Dimensions W x D (including speaker terminals) x H (including feet): W432 x D459.1 x H170mm
Weight (net): 22.7kg
Weight (packed): 29.4kg
Region Specific Power Cord(s)
Rear panel cowl
Remote control with 2 x AAA batteries
Measurement Microphone
5m USB Cable
Quick Start Guide
Important Safety Instructions
Bluetooth Version: 5.4
Bluetooth Profiles: A2DP Sink/Source, AVRCP, Snapdragon Sound, AAC, LE Audio, Auracast, GATT, VCP, MCP, BAP, CAP
Bluetooth Transmitter Frequency Range and Power:
2,402 MHz to 2,480 MHz <Max 10.73dBm
Wi-Fi Network: IEEE 802.11 a/b/g/n/ac (2.4GHz/5GHz)
2.4G Wi-Fi Transmitter Frequency Range and Power:
2.400 GHz to 2.4835 GHz < Max 17.4dBm
5G Wi-Fi Transmitter Frequency Range and Power:
5.15-5.35GHz, 5.47-5.725GHz, 5.725-5.875GHz, < Max 19.26dBm
