ARCAM's AVR15 uses clean amplification and other top-quality internal circuitry for high-end surround sound performance. The amp's 9 channels let you run a full Dolby Atmos or DTS:X surround sound speaker setup, and 12-channel preamp outputs offer expansion capability. Have 7 speakers or fewer? Use the extra amp channels to double the power to bi-ampable front speakers.
The AVA15 brings breathtaking clarity and depth to every note and every scene, putting you at the heart of the performance.
Expertly engineered in Cambridge, UK, and built on over 30 years of surround sound expertise, the AVA15 combines our passion for music with cutting-edge technology. Its powerful Class D amplification and advanced immersive audio processing deliver a sound that’s as thrilling as it is precise.
With nine channels of amplification, the AVA15 drives setups like 7.1.2 or 5.1.4 with ease—and gives you room to expand with extra subwoofers, height, or surround speakers. Dolby Atmos and DTS:X bring cinema-grade immersion to your home, while Dirac Live room correction ensures every detail sounds perfect in your space.
At ARCAM, sound quality isn’t just a promise—it’s our obsession. The AVA15 is the result of rigorous testing and listening sessions to award it the ARCAM name.
And with a vibrant 6.5" colour display, intuitive on-screen menus, and the new Radia App, setup and streaming are effortless.
Nine channels of high power ARCAM Class D Amplification.
Dolby Atmos - Bring even the smallest details to life with sound that moves in all directions.
DTS:X - places sound where it would occur naturally in space, creating the most lifelike, multi-dimensional audio experience ever.
Dirac Live Room Correction for exceptional, calibrated audio in any room - upgrade with Dirac Live Bass Control and Dirac Live Active Room Treatment
Back-lit, Bluetooth remote control for continuous out-of-sight control
Works with the new ARCAM Radia AV Control app for setup, control, Internet Radio, Podcasts and UPnP playback from iOS, Android and Windows devices and PCs.
Works with Spotify Connect, Tidal Connect and Qobuz Connect, with direct connection from lossless music services
Roon Ready
Supports Apple Airplay and Google Cast
Bluetooth with Snapdragon Sound and Auracast for the best wireless sound with the most convenience
Large High-resolution display for clearly visible status and metadata from the comfort of your main listening position
Plastic free packaging for easy disposal of natural materials
Maximum Channel Count: 12
Reassignable Channels:
Front, Surround Back, Height Channels
Supported Decoding and Encoding:
Dolby Atmos, Dolby TrueHD, Dolby Atmos Height Virtualisation, Dolby Surround
DTS:X, DTS HD Master, DTS Neural:X, DTS Virtual:X
MPEG H
Inputs/Outputs: 7/2
HDMI/HDCP Versions: 2.1a/2.3
Resolution support (resolution/framerate):
Up to 8K/60Hz or 4K/120Hz
Supported Dynamic Range Profiles:
HDR, HDR10, HDR10+, HDR10+ Gaming, Dolby Vision, HLG
Supported HDMI features:
Variable Refresh Rate (VRR), Auto Low Latency Mode (ALLM), CEC, eARC/ARC (Output 1) On Screen Display
Works with (apps):
ARCAM Radia AV Control, Spotify Connect, Tidal Connect, Qobuz Connect, Roon (Ready)
Works with (services):
Apple Airplay, Google Cast, Internet Radio, Podcasts, UPnP
Supported Hi-res media:
FLAC, WAV (LPCM), AAC, ALAC, AIFF, MP3, OGG
Gapless Playback Supported
Supported Hi-res Bit depth: 16, 24
Supported samples rates (kHz): Up to 192 kHz
Frequency response: 20Hz—20kHz ± 0.05dB
Number of inputs (Coaxial/Toslink): 2/2
Supported Sample Rates (kHz):
Coaxial (RCA): 192, 176.4, 96, 88.2, 48, 44.1
Optical (Toslink): 96, 88.2, 48, 44.1
Bit depths (bit) (Coaxial/Toslink): 24, 16
Frequency response: 20Hz—20kHz ± 0.2dB
Signal/noise ratio (A-wtd, ref. 50W, 0dBFS): 100dB
Number of inputs: 3 (RCA pairs)
Signal/noise ratio (A-wtd, ref. 50W, 1V input): 100dB
Frequency response: 20Hz—20kHz ± 0.2dB
Number of Outputs RCA/XLR: 12/0
Single-ended (RCA) peak output level per channel: 2V RMS
THD+N (20 Hz to 20 kHz): –100dB
Amplifier Channels: 9, Class D
8O, 20Hz - 20kHz, 2 channels driven: 85W
4O, 1kHz, 2 channels driven: 150W
8O, 20Hz - 20kHz, 7 channels driven: 85W
4O, 1kHz, 7 channels driven: 65W
Harmonic distortion @80% power, 8O at 1kHz: 0.003%
Mains voltage (V/Hz): 100–120V or 220–240V, 50–60Hz
Max Power consumption: 900W
Max Thermal dissipation: 3070 BTU/hour
Idle Power consumption: 59W
Idle Thermal dissipation: 200 BTU/hour
Standby Power consumption (Default/Low Power): 2W/0.3W
Dimensions W x D (including speaker terminals) x H (including feet): W432 x D407.4 x H170mm
Weight (net): 10kg
Weight (packed): 15.7kg
Region Specific Power Cord(s)
Rear panel cowl
Remote control with 2 x AAA batteries
Measurement Microphone
5m USB Cable
Quick Start Guide
Important Safety Instructions
Bluetooth Version: 5.4
Bluetooth Profiles: A2DP Sink/Source, AVRCP, Snapdragon Sound, AAC, LE Audio, Auracast, GATT, VCP, MCP, BAP, CAP
Bluetooth Transmitter Frequency Range and Power:
2,402 MHz to 2,480 MHz <Max 10.73dBm
Wi-Fi Network: IEEE 802.11 a/b/g/n/ac (2.4GHz/5GHz)
2.4G Wi-Fi Transmitter Frequency Range and Power:
2.400 GHz to 2.4835 GHz < Max 17.4dBm
5G Wi-Fi Transmitter Frequency Range and Power:
5.15-5.35GHz, 5.47-5.725GHz, 5.725-5.875GHz, < Max 19.26dBm
