Crafted. Honed. Perfected.
Engineered for pristine studio-quality sound at home, the 702 S3 Signature utilizes upgraded midrange and low-frequency motor systems, improved capacitors, revised speaker terminals, plus a more open tweeter grille mesh, as developed for our 800 Series Signature loudspeakers.

• Technical Features
• Decoupled Carbon Dome Tweeter
• Solid Body Tweeter-on-Top
• Continum cone FST midrange
• Decoupled midrange
• Aerofoil Profile bass cones
• Flowport
• Description: 3-way vented-box system
• Drive Units
• 1 xø25mm (1 in) Decoupled Carbon Dome high-frequency
• 1 xø150mm (6 in) Continuum cone FST midrange
• 3x ø165mm (6.5 in) Aerofoil Profile bass
• Frequency Range: -6ddB 28 Hz – 33kHz
• Frequency Response (3 +/-3db from reference axis): 46Hz – 28 Hz ±3dB
• Sensitivity (on axis at 2.83Vrms at 1m): 90dB
• Harmonic Distortion
• 2nd and 3rd harmonies (90dB, 1m on axis)
• <1% 86Hz – 28 kHz
• <0.5% 100 Hz – 20 kHz
• Nominal Impedance: 8Ω (minimum 3.1Ω)
• Recommended Amplifier Power: 30W – 300W into 8Ω on unclipped programme
• Max Recommended Cable Impedance: 0.1Ω
• Dimensions
• Height: 1,010 mm (39.8 in) cabinet only, 1,138 mm (44.8 in) including tweeter and plinth
• Width: 192 mm (7.6 in) cabinet only, 290 mm (11.4 in) including plinth
• Depth: 354 mm (13.9 in) cabinet only, 410 mm (16.1 in) including plinth, 391 mm (15.4 in) including grille and terminals
• Net Weight: 39.5 kg (87.1 lbs)
• Finishes
• Cabinet: Datuk Gloss, Midnight Blue Metallic
• Grille: Black
