Naim NAC 282 Preamplifier

PRICE:
Regular price $8,599.00 USD
Regular price $8,599.00 USD Sale price $8,599.00 USD
Sale Sold out

Shipping calculated at checkout.

CONDITION: New

description

Overview

Step up from the NAC 202 and you arrive at the outstanding NAC 282, which includes the NAPSC power supply unit optionally available on its sibling. The NAPSC independently powers the NAC 282’s digital and control circuits, leaving its audio circuits to either the power supply of a NAC 155 XS or NAP 200 power amplifier, or to one of our standalone FlatCap XS, HiCap or SuperCap power supplies. The result is even greater transparency and superior musicality plus, of course, all the flexibility you’d expect from one of our preamplifiers

Technology & Craft

Low resonance circuit boards and anti-vibration, resonance control feet maximise isolation, hence minimizing the effects of microphonic vibration on the highly sensitive electronic components.

The NAC 282 features a silent microprocessor that sleeps during listening and controls all aspects of the amplifier. Optical protection circuits continuously monitor the power supplies ensuring safe shut-down in the event of a power cut.

A user configurable 'Smart IR' system remote control is supplied. Two of the six inputs on the Naim Audio NAC 282 can be configured either as the usual DIN inputs, preferred for their superior earthing and impedance matching, or for use with the more common RCA phono connectors, allowing a wide range of non-Naim Audio cables and components to be used. A dedicated unity-gain input is provided for use with the Naim Audio AV2 processor or similar.

Features

Support for both DIN and RCA inputs to facilitate connection into a wider range of systems

Silent microprocessor control that sleeps during listening

Precision rotary potentiometers with precious metal wipers

AV bypass mode for simple connection to an existing AV system

Powered input for use with StageLine or SuperLine phono stages

Performance upgradable with FlatCap XS, HiCap or SuperCap power supply; can also be powered from the preamp inputs of the NAP 155 XS or NAP 200 power amplifier

Technology & Craft

The Naim Audio NAP 300 delivers immense power without sacrificing any speed or agility to provide awe-inspiring levels of detail and musicality

Like the flagship Naim Audio NAP 500, the NAP 300 is a stereo two-chassis amplifier, one box containing the audio amplifier and the second housing the power supply. Improved earthing arrangements have resulted in an entirely new circuit topology built on a very high quality, anti-resonance main audio circuit board. The NAP 300 uses the same NA009 transistors that were custom-designed for the Statement NAP S1. These outstanding components each provide up to 80 Amps and 350 watts, negating the need to use parallel pairs of transistors (which always has a negative effect on sound). Additional NA009 transistors are used in the fully regulated power supply, ensuring the very best performance.

A variable speed, virtually noiseless cooling fan is mounted on a large internal heat sink providing long-term stability and the ability to swing a massive 500 VA on transients. The NAP 300 is stable into any load and able to drive a 2-Ohm load for long periods of time.


Specifications

Audio Inputs
Other Inputs

AV input configurable for unity gain

Input Impedance

47kΩ

Analogue Input

4 x DIN, 2 x DIN, RCA

Input Sensitivity

75mV

Audio Outputs
Audio Outputs

2 x variable (DIN), 3 x fixed (DIN)

Other Outputs

<50Ω

Line Outputs Variable (level)

775mV

Line Outputs Fixed (level)

75mV, 600Ω

Load Impedance

10kΩ (min.)

Power Outputs

Naim phono amplifier

Connectivity
RS232

Optional (DE9 female)

Remote Input

RCA on rear (RC5)

Finish
Case

Black powder coated

Front

Brushed and black anodised

Physical
Weight

7.0 kg

Dimensions (HxWxD)

87 x 432 x 314 mm

Power
Power Supply Options

NAP 155 XS, NAP 200, FlatCap XS, HiCap, SuperCap

Supply Voltage

18V, 24V

Supplied with
Supplied with

NARCOM-4 Remote Control

Upgrades
Power Supply

2 x Hi-Cap/SuperCap

Other

NAPSC

User Control
Front Panel

Volume control, balance control, sixteen button matrix

Handheld

NARCOM-4 Remote Control

Remote Control

Infra Red (RC5)
