U2 SPECIFICATION
-
DSD SUPPORT:
- Up to DSD512 22.5MHz, 1-bit
-
PCM SUPPORT:
- Up to 768kHz, 16–32-bit, Stereo
-
UPSAMPLING RATES & BIT DEPTHS:
- DSD256 upsampling option for all files
- PCM 384kHz upsampling option for all files
-
DIGITAL OUTPUT STAGE:
-
USB:
- Native DSD512 support
- PCM 44.1–768kHz, 16–32-bit, Stereo
-
OPTICAL, COAXIAL RCA, COAXIAL BNC & AES/EBU:
- PCM 44.1kHz–192kHz, 16–24-bit
- DSD (DoP, DSD over PCM) 2.8MHz, 1-bit
-
-
OPTICAL NETWORK:
- Industry-standard SFP
- 1000Base-T Gigabit Ethernet
- Adapter may be needed for your particular switch/cables
- Use simultaneously with RJ45 (e.g. connect one to router and one to LUMIN L1 or NAS)
-
POWER SUPPLY:
- Internal toroidal linear
- Low-noise linear regulator
-
PHYSICAL:
-
FINISH:
- Black anodised aluminium
- Raw anodised aluminium
DIMENSIONS
- 350mm (W), 350mm (D), 60.5mm (H), 6kg
-
